| Standard | ||||
| 1.1 | Model | MQC35 | MQC40 | |
| 1.2 | Power type | Battery | Battery | |
| 1.3 | Operation type | Seated | Seated | |
| 1.4 | Rated load | Q(kg) | 3500 | 4000 |
| 1.5 | Load center | C(mm) | 600 | 600 |
| 1.6 | Front overhang | x(mm) | 325 | 325 |
| 1.7 | Wheelbase | y(mm) | 1800 | 1800 |
| Weight | ||||
| 2.1 | Service weight(incl.battery) | kg | 6370① | 6370① |
| Wheel | ||||
| 3.1 | Wheel type | Rubber solid wheel | PU | |
| 3.2 | Load wheel size | mm | 14×5/φ356×127 | φ350×110(2pc) |
| 3.3 | Drive wheel size | mm | 16×7/φ406×178 | 16×7/φ406×178 |
| 3.4 | Number of wheels, front/rear(x=drive wheel) | 4/2X | 4 / 2X | |
| 3.5 | Wheel tread, drive side | b10(mm) | 1760 | 1760 |
| 3.6 | Wheel tread, load side | b11(mm) | 1712 | 1712 |
| Size | ||||
| 4.1 | Mast tilting | α/β(°) | 2/4 | 2/4 |
| 4.2 | Mast closed height | h1(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.3 | Free lift height | h2(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.4 | Lift height | h3(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.5 | Mast extended height with load-backrest | h4(mm) | Refer to the mast specification | Refer to the mast specification |
| 4.6 | Cabin height(with light/without light) | h6(mm) | 2674/2547 | 2674/2547 |
| 4.7 | Seat height | h7(mm) | 1365 | 1365 |
| 4.8 | Leg height | h8(mm) | 475 | 475 |
| 4.9 | Overall length | l1(mm) | 2300 | 2300 |
| 4.10 | Overall width | b1/b2(mm) | 2435/2860 | 2435/2860 |
| 4.11 | No-load turn around diameter | WK(mm) | 3210 | 3210 |
| 4.12 | Fork size | l/e/s(mm) | 1200×150×50 | 1200×150×50 |
| 4.13 | Fork carriage width | b5(mm) | 2860 | 2860 |
| 4.14 | Fork outside width | b3(mm) | 610-2800 | 610-2800 |
| 4.15 | Inner leg width | b4(mm) | 1150 | 1150 |
| 4.16 | Reach stroke | l4(mm) | 1300 | 1300 |
| 4.17 | Min ground clearance | m1(mm) | 124 | 124 |
| Function | ||||
| 5.1 | Straight driving speed,load/unloaded | km/h | 7/8 | 7/8 |
| 5.2 | Side driving speed,load/unloaded | mm/s | 6/7 | 6/7 |
| 5.3 | Lifting speed,load/unloaded | mm/s | 150/250 | 150/250 |
| 5.4 | Lowering speed,load/unloaded | mm/s | 195/160 | 195/160 |
| 5.5 | Straight Max Gradeability, Load/Unloaded(S2-5min) | %(tanθ ) | 8/8 | 8/8 |
| 5.6 | Side Max Gradeability, Load/Unloaded(S2-5min) | %(tanθ ) | 8/8 | 8/8 |
| 5.7 | Braking method | Electromagnetic | Electromagnetic | |
| Drive | ||||
| 6.1 | Drive motor power (S2-60min) | kw | 8AC | 8AC |
| 6.2 | Lift motor power (S3-15%) | kw | 15AC | 15AC |
| 6.3 | Lead acid battery, voltage/capacity | V/Ah | 48/560 | 48/560 |
| 6.4 | Battery weight | kg | 910 | 910 |
| 6.5 | Steering system | EPS | EPS | |
| Others | ||||
| 7.1 | Battery replacement | Hoisting | Hoisting | |
| Standard configuration:fork positioner | ||||
